SPECIFICATIONS

Brand Name: ZMFJH

Interchange Part Number: CX6069

Item Weight: 400g

Manufacturer Part Number: 3 in 1 Multi-Function Digital Gauge

Other Part Number: TFT Screen

Placement on Vehicle: Front

Material Type: Stainless steel +Plastic

Item Length: 52mm

Special Features: Waterproof

Item Width: 52mm

Item Height: 52mm

Item Name:: 3 in 1 Multi-Function Digital Gauge

Temperature sensor:: 301-22ohm

Oil Pressure:: 0-10 bar

Pressure sensor:: 10-184ohm

Voltmeter:: 9-32V

Alarm:: Symbal flashing

Degree of Protection:: IP67

Backlight:: TFT Screen

Engine Oil Pressure:: 0-10 Bar

Water Temperature:: 40-120Celsius degree



Speficication :

- Water Temperature: 40-120℃ (Temperature sensor: 301-22ohm)

- Oil Pressure: 0-10 bar (Pressure sensor: 10-184ohm)

- Water Level: 0-100% (Level sensor: 0-190ohm/240-33ohm available)

- Holding Tank: 0-100%

-Tachometer :0-9999 RPM

* Sensor are not provided with this gauge.

* Plz. order the sensor separately if you need it.

- Voltmeter: 9-32V

- Alarm: Symbal flashing(When 2 or more faults occur, an item is reported every 3s.)

- Degree of Protection: IP67

- Backlight: TFT Screen

Alarm(Flash) :

-Oil Temp more than 108℃ ;
-Water temp more than 95℃;
-HTG more than 75%;
-Oil pressure less than 0.8bar;
-Fuel Level less than 13%;
-Fresh Level less then 13%;
-12v System less than 11.5V;
-24v System less than 22V.

Package Included:

- 1X 3 in 1 Multi-function Gauge

- 1XMulti-plug socket

- 1XInstruction

Dimensions :

- 52mm diameter (2")
- 55mm Depth (2-3/4")
